| Part Number | Description | Crusher Type | Weight |
| 1001998508 | CAP 8 FNTX-S | HP100 | 0.045 |
| 1002077185 | ADAPTER 202702-20-20S | HP100 | 0.340 |
| 7001530102 | SCREW HEX ISO4017-M8X20-8.8-A3A | HP100 | 0.012 |
| 7001532104 | SCREW HEX ISO4017-M8X30-10.9-UNPLTD | HP100 | 0.100 |
| 7001532204 | BOLT HEX ISO4014-M12X50-10.9-UNPLTD | HP100 | 0.052 |
| 7001532263 | BOLT HEX ISO4014-M14X60-10.9-UNPLTD | HP100 | 0.100 |
| 7001532416 | BOLT HEX ISO4014-M20X80-10.9-UNPLTD | HP100 | 0.200 |
| 7001540130 | CAP SCRW HEXSCKTHD ISO4762-M8X20-12.9-A | HP100 | 0.100 |
| 7001563014 | NUT HEX ISO4032-M14-8-A3A | HP100 | 0.024 |
| 7001563248 | NUT HEX ISO4032-M48-10-UNPLTD | HP100 | 1.000 |
| 7001614318 | PIN ISO8741-25X55-ST | HP100 | 0.200 |
| 7001624014 | WASHER L-14-ZIN-NFE27-611 | HP100 | 0.020 |
| 7001626008 | WASHER M-8-ZIN-NFE27.611 | HP100 | 0.002 |
| 7001626020 | WASHER M-20-ZIN-NFE27.611 | HP100 | 0.023 |
| 7001631114 | WASHER M14-NFE25.511-UNPLATED | HP100 | 0.100 |
| 7001638012 | WASHER M12-NFE27.611-A3A-ISO4042 | HP100 | 0.100 |
| 7001836108 | EYE BOLT ISO3266-M8-WLL 0.2T | HP100 | 0.060 |
| 7002002016 | BUSHING ISO49-N4-II-1 1/4X1/2-ZN-A | HP100 | 0.200 |
| 7002002023 | BUSHING ISO49-N4-II-1 1/2X1-ZN-A | HP100 | 0.100 |
| 7002002030 | BUSHING ISO49-N4-II-2X1 1/2-ZN-A | HP100 | 0.300 |
| 7002002054 | BUSHING ISO49-N4-II-4X3-ZN-A | HP100 | 1.400 |
| 7002019004 | UNION ISO49-U12-1/2-ZN-A | HP100 | 0.300 |
| 7002019012 | UNION ISO49-U12-3-ZN-A | HP100 | 2.700 |
| 7002045007 | ELBOW EN10242-A1-1″1/4 | HP100 | 0.400 |
| 7002046004 | ELBOW ISO49-A4-1/2-ZN-A | HP100 | 0.100 |
| 7002046012 | ELBOW ISO49-A4-3-ZN-A | HP100 | 1.700 |
| 7002063010 | ELBOW ISO49-G4/45°-3-ZN-A | HP100 | 2.200 |
| 7002118031 | COLLAR SX14 24-36 | HP100 | 0.020 |
| 7002118051 | CLAMP SX 14 47-67 | HP100 | 0.020 |
| 7002118076 | CLAMP SX 14 122-142 | HP100 | 0.050 |
| 7002118803 | CLAMP TP 98-103 | HP100 | 0.200 |
| 7002153025 | PRESSURE LIMITER MILLE.,,,,,,,, – 1″1/2 | HP100 | 5.400 |
| 7002407154 | CNNCTN MALE GG110-NP16-16 | HP100 | 0.200 |
| 7002411080 | STRAIGHT ADAPTER 221501-12-8S | HP100 | 0.150 |
| 7002445900 | ACCESS DOOR R8-012 | HP100 | 0.000 |
| 7002470090 | GASKET SET | HP100 | 0.300 |
| 7002495410 | PROTECTION LB1-LB03P17 | HP100 | 0.500 |
| 7002707040 | SEAL PU 40X40 – 46/120 | HP100 | 0.001 |
| 7003229848 | DTACHBL HUB PULLEY ML355 SPC6/3535 | HP100 | 48.100 |
| 7003239236 | HUB MAGIC-LOCK 4040 BORE 80 | HP100 | 7.200 |
| 7003770060 | CAM FOLLOWER KR 80 PPA | HP100 | 1.600 |
| 7008010004 | PIPE SEALANT 572 | HP100 | 0.290 |
| 7008010040 | SILICONE SEAL SILICOMET AS310 | HP100 | 0.456 |
| 7010600102 | COOLER TYPE 2560 | HP100 | 20.000 |
| 7012080200 | TORCH RING HP100 | HP100 | 2.000 |
| 7015554502 | BUSHING | HP100 | 0.500 |
| 7015604504 | CNTRSHFT BUSHING | HP100 | 3.700 |
| 7015655250 | ECCENT BUSH INNER | HP100 | 11.000 |
| 7015656202 | HEAD BUSHING | HP100 | 25.400 |
| 7021900200 | MAIN FRAME LINER | HP100 | 117.900 |
| 7022023212 | LINER | HP100 | 31.100 |
| 7022072500 | CNTRWGHT LINER | HP100 | 32.000 |
| 7022102000 | CNTRSHFT GRD | HP100 | 9.200 |
| 7022102001 | ARM GUARD | HP100 | 20.000 |
| 7024950501 | HEAD BALL | HP100 | 14.000 |
| 7028000463 | PROTECTION COVER | HP100 | 5.000 |
| 7029550009 | HYDR JACK | HP100 | 3.000 |
| 7031800009 | WRENCH LOCKING | HP100 | 5.600 |
| 7032902500 | WEDGE | HP100 | 0.300 |
| 7033100017 | OIL FLINGER | HP100 | 3.200 |
| 7039608500 | SOCKET | HP100 | 33.000 |
| 7039608501 | SOCKET | HP100 | 33.000 |
| 7041000953 | NUT SPHERICAL H,M20 | HP100 | 0.100 |
| 7041068004 | BOLT LOCK | HP100 | 8.800 |
| 7043200005 | U-BOLT M10X80 | HP100 | 0.200 |
| 7043358005 | ECCENTRIC | HP100 | 94.000 |
| 7044453046 | HYDR HOSE HP 9,5 L=8000 | HP100 | 5.800 |
| 7044453057 | HYDR HOSE HP 9,5 L=610 | HP100 | 0.500 |
| 7045600100 | NUT-LOCK U C/PL.32 | HP100 | 0.500 |
| 7049330250 | PIN 25X80 | HP100 | 0.300 |
| 7053001001 | SEAL RING | HP100 | 0.100 |
| 7053125500 | SEAL RING | HP100 | 0.300 |
| 7053128252 | SEAL RING | HP100 | 0.300 |
| 7053128253 | SEAL RING | HP100 | 0.300 |
| 7055208000 | BOWL LINER EF | HP100 | 237.000 |
| 7055208001 | BOWL LINER F/M | HP100 | 256.000 |
| 7055208002 | BOWL LINER C | HP100 | 246.000 |
| 7055208003 | BOWL LINER EC | HP100 | 244.000 |
| 7055308121 | MANTLE M/C/EC/SC | HP100 | 220.000 |
| 7055308122 | MANTLE EF/F | HP100 | 222.000 |
| 7057500003 | HYDR MOTOR ASSY | HP100 | 118.000 |
| 7059801000 | INFLATER CHECKER EVERYWHERE EXCEPT EURO | HP100 | 0.500 |
| 7063002250 | PINION | HP100 | 9.000 |
| 7063002401 | PINION | HP100 | 13.500 |
| 7064351010 | INSTR PLATE | HP100 | 0.000 |
| 7065558000 | FEED CONE | HP100 | 3.000 |
| 7065558001 | FEED CONE | HP100 | 3.000 |
| 7066000132 | SUPPORT PLATE | HP100 | 15.000 |
| 7074129000 | THRUST BRNG LOW | HP100 | 6.500 |
| 7074129001 | THRUST BRNG UPR | HP100 | 6.000 |
| 7078610000 | RING | HP100 | 0.100 |
| 7080500418 | SUPPORT | HP100 | 1.000 |
| 7080500423 | SUPPORT | HP100 | 33.000 |
| 7084101513 | FRAME SEAT LINER | HP100 | 7.500 |
| 7084101700 | PROTECTION PLATE | HP100 | 2.900 |
| 7088010082 | TRAMP RELEASE CYL | HP100 | 56.000 |
| 7088462250 | BOLT SQUARE HEAD M20X55/50 | HP100 | 0.100 |
| 7090058305 | FEED CONE OPTION | HP100 | 12.000 |
| 7090228107 | CNTRWGHT ASSY | HP100 | 158.200 |
| MM0217965 | INTERFACE MOD 6ES7 151-1AA05-0AB0 | HP100 | 0.190 |
| MM0225155 | ELCTRC CABLE UNITRONIC LIYCY 2X0.50, 00 | HP100 | 0.000 |
| MM0227546 | V-BELT SPC 3750MM | HP100 | 0.000 |
| MM0227609 | MOTOR Y2-280M-4/90KW380C/50HZ | HP100 | 0.000 |
| MM0227826 | ELECTRIC CABLE H013 | HP100 | 0.000 |
| MM0287691 | WASHER SPRING W8-NFE25.515-A3A | HP100 | 0.005 |
| MM0544964 | BOWL LINER SPECIAL C | HP100 | 247.800 |
| MM0545036 | BOWL LINER SPECIAL STD M | HP100 | 267.300 |
| N02150058 | PUMP KP30.51D0-33S3-LGG/GF-N (73L/MIN) | HP100 | 13.900 |
| N02150061 | PUMP HDP35.90D0-33S5-LGG/GG-N (129L/MIN | HP100 | 25.800 |
| N02445269 | PRSSR ACCUMULATOR SB330-4A4/112US-330C | HP100 | 15.500 |
| N02445647 | PRSSR ACCUMULATOR EHV 4-350/90 | HP100 | 11.000 |
| N02480819 | PRESSURE SW HED8OP/1X/200K14, 25BAR | HP100 | 0.500 |
| N02480897 | PRSSR REL VALVE RDBA-LDN, 28 BAR | HP100 | 0.100 |
| N02480898 | PRSSR REL VALVE RDBA-LDN, 35 BAR | HP100 | 0.100 |
| N02482023 | RETURN FILTER RFM BN/HC 1650 B D 20 E1. | HP100 | 0.454 |
| N05228037 | ROT DTCTR MS25-UI/24VDC | HP100 | 0.260 |
| N25450517 | STUFFING-BOX HP100 A HP500 | HP100 | 4.000 |
| N55208010 | BOWL LINER SPECIAL EF | HP100 | 220.000 |
| N55308129 | MANTLE SPECIAL EF | HP100 | 195.000 |
| N73210500 | SPRING | HP100 | 0.025 |
| N90058031 | HEAD ASSEMBLY STD | HP100 | 360.000 |
| N90155810 | RELEASE KIT | HP100 | 16.000 |
| N90198708 | DUST ENCAPSUL ASSY STD | HP100 | 44.500 |
| N90198905 | SENSOR ASSY | HP100 | 1.600 |
| N90258013 | BOWL ASSY STD | HP100 | 1,225.500 |
