TIME：2022-07-31
| Part Number | Description | Crusher Type | Weight |
| 1001603714 | CHECK VALVE P/N CVFP-12-N-0-005, CHOKE C | HP800 | 0.290 |
| 1001603716 | CHECK VALVE PILOT OPERATED, P/N POCI-10 | HP800 | 0.160 |
| 1001603755 | PLUG ORIFICE, SAE WITH 0.026″ DIA ORIFI | HP800 | 0.000 |
| 1001603757 | PLUG ORIFICE, SAE WITH 0.093″ DIA ORIFI | HP800 | 0.010 |
| 1001614602 | VALVE W/MOD’S PER DWG, NEEDLE TYPE, P/N | HP800 | 0.200 |
| 1001623523 | PRESSURE RELIEF VALVE PARKER RAH 101 D50 | HP800 | 0.190 |
| 1001623524 | PRESSURE RELIEF VALVE RELIEF TYPE, P/N R | HP800 | 0.180 |
| 1001623526 | PRESSURE RELIEF VALVE RVDA-10-N-S-0-50/3 | HP800 | 0.180 |
| 1001690017 | SHUTTLE VALVE P/N BDSV-10-N-3-0 | HP800 | 0.140 |
| 1001697909 | PRESSURE REDUCING VALVE 350 PSI, P/N PRP | HP800 | 0.190 |
| 1001738082 | SAFETY VALVE RELIEF VALVE (SET TO 150 PS | HP800 | 9.390 |
| 1002077195 | UNION 1.875″-12UNF-2A, O-RING TYPE, 24 F | HP800 | 0.510 |
| 1003725634 | BOLT HEX ISO4014-M30X90-8.8-UNPLTD | HP800 | 0.710 |
| 1003894084 | FILTER ELEMENT S/B MM0297258 | HP800 | 1.510 |
| 1005194218 | PRESSURE SWITCH SET TO CLOSE AT 2200 PSI | HP800 | 0.907 |
| 1005194219 | PRESSURE SWITCH SET TO CLOSE 2500-2550 | HP800 | 0.907 |
| 1005465512 | RET RING 5.125″IDX0.072″ THK, RS-512 | HP800 | 0.040 |
| 1017557223 | V-BELT 8V/355/SET OF 3 BANDED, 14 TOTAL | HP800 | 94.000 |
| 1019559608 | BOLT LOCK HP800 | HP800 | 136.000 |
| 1019584408 | BOLT SQUARE HEAD M56 X 5.5-6G X 140 MM | HP800 | 5.400 |
| 1019584409 | BOLT SQUARE HEAD M56 X 5.5-6G X 170MM L | HP800 | 5.860 |
| 1020057058 | BOWL SHORT HEAD, HP800, PHASE 1, ALSO WF | HP800 | 8,400.000 |
| 1021790058 | BRAKE 92B-3-B-2-G043-B | HP800 | 9.100 |
| 1022066795 | CNTRSHFT BUSHING MACHINING | HP800 | 3.300 |
| 1022075464 | ECCENTRIC BUSHING | HP800 | 211.000 |
| 1022147711 | HEAD BUSHING UPR | HP800 | 81.000 |
| 1022147721 | HEAD BUSHING LOW | HP800 | 253.000 |
| 1022147723 | HEAD BUSHING LOW | HP800 | 302.000 |
| 1026740193 | HEAT EXCHANGER 2 PASS TCF TYPE, 90/10 C | HP800 | 50.267 |
| 1026888195 | FLEXIBLE COUPLING 1.250″ BORE PUMP, 0.3 | HP800 | 1.060 |
| 1026889923 | COUPLING FOR JACK SHAFT | HP800 | 180.000 |
| 1026889924 | FLEXIBLE COUPLING | HP800 | 651.810 |
| 1026950074 | PIPE UNION NH1650X300X0650 | HP800 | 4.200 |
| 1030415068 | FEED DISTRIBUTOR | HP800 | 320.000 |
| 1031143668 | ECCENTRIC | HP800 | 2,151.000 |
| 1031402026 | INST KITS AIMING, P/N EASY AIMER-2 / 5 | HP800 | 2.270 |
| 1031402051 | SENSOR ULTRASONIC LEVEL DETECTOR, MP’S | HP800 | 2.700 |
| 1031409015 | ELECTRONIC PART 56K LAN MODEM FOR TC AUT | HP800 | 0.000 |
| 1031409018 | PROCESSOR UNIT MICROLOGIX 1500 PROCESSO | HP800 | 0.400 |
| 1031409029 | END CAP 1769-ECR | HP800 | 0.130 |
| 1035718177 | O-RING 20.47″ID X 22.22″OD X .875″THK, 6 | HP800 | 0.960 |
| 1035718180 | O-RING 21.20″ID X 22.45″OD X .625″THK, | HP800 | 0.520 |
| 1036831540 | PINION SPIRAL BEVEL HP800 | HP800 | 186.000 |
| 1036831550 | PINION CONIFLEXED | HP800 | 214.000 |
| 1036831560 | BEVEL GEAR SPIRAL BEVEL GEAR | HP800 | 608.000 |
| 1038018752 | GUARD STATIONARY COUNTERWEIGHT | HP800 | 152.000 |
| 1038069628 | CNTRSHFT BOX GRD | HP800 | 22.400 |
| 1038069629 | CNTRSHFT BOX GRD HP800 | HP800 | 76.200 |
| 1038069733 | ARM GRD | HP800 | 151.950 |
| 1042472605 | HEAD MACHINING | HP800 | 5,382.000 |
| 1044252010 | HOSE ASSEMBLY 0.38″ID X 8.70″LG, W/2 SW | HP800 | 0.270 |
| 1044252028 | HOSE ASSEMBLY 0.375″ID X 11.800″LG, W/1 | HP800 | 0.280 |
| 1044252037 | HOSE ASSEMBLY .38″IDX17.1″LG, W/2 FLARE | HP800 | 0.320 |
| 1044252051 | HOSE ASSY .38″ID X 14.4″LG, W/1 FLARE & | HP800 | 0.440 |
| 1044252538 | HOSE ASSEMBLY .38″ID X 29.3″LG, W/1 FLA | HP800 | 0.590 |
| 1044254083 | HOSE ASSEMBLY 0.75″ID X 33.90″LG W/1 ML | HP800 | 0.700 |
| 1045376433 | CNTRSHFT BOX | HP800 | 766.000 |
| 1048314344 | BOWL LINER STD X-COARSE | HP800 | 3,120.000 |
| 1048314364 | BOWL LINER SHORT HEAD, MEDIUM | HP800 | 4,121.000 |
| 1048517411 | MAIN FRAME LINER | HP800 | 700.000 |
| 1048517581 | FRAME SEAT LINER SET OF 6 | HP800 | 48.000 |
| 1048724025 | SOCKET LINER | HP800 | 196.000 |
| 1050143810 | MANTLE SH HD-MED & CSE | HP800 | 2,687.000 |
| 1050143849 | MANTLE STANDARD | HP800 | 3,075.000 |
| 1050143852 | MANTLE SHORT HEAD, MEDIUM & FINE | HP800 | 4,543.000 |
| 1050230068 | HYDR MOTOR OILGEAR HYDURA HYDRAULIC DRIV | HP800 | 31.000 |
| 1050230079 | HYDRAULIC MOTOR OILGEAR HYDURA, P/N GS0 | HP800 | 32.900 |
| 1054268776 | CLEVIS PIN TRAMP RELEASE CYLINDER | HP800 | 8.660 |
| 1055981161 | FEED PLATE | HP800 | 82.000 |
| 1055981162 | FEED PLATE | HP800 | 130.000 |
| 1057612405 | THRUST BRNG | HP800 | 89.000 |
| 1057612406 | THRUST BRNG LOWER | HP800 | 78.000 |
| 1057612407 | THRUST BRNG LOW | HP800 | 78.000 |
| 1057612434 | HEAD BALL | HP800 | 249.000 |
| 1059422506 | PUMP OIL PUMP, OIL GEAR PVW-20, P/N GS00 | HP800 | 31.000 |
| 1059428075 | PUMP ASSEMBLY OIL, W/O RELIEF VALVE, 3′ | HP800 | 73.000 |
| 1059640387 | REDUCER C SIZE, 2.80:1 RATIO, 3-551-032 | HP800 | 39.460 |
| 1061876265 | CLAMPING RING | HP800 | 1,316.000 |
| 1061877930 | ADJSTM RING | HP800 | 6,383.000 |
| 1062440052 | RING DRIVER | HP800 | 590.000 |
| 1062807444 | OIL FLINGER | HP800 | 21.000 |
| 1062870306 | O-RING FOR HYD DRIVE RETRO FIT KIT 94399 | HP800 | 0.020 |
| 1062870307 | SEAL O-RING SEAL, P/N 2-250 | HP800 | 0.020 |
| 1063192525 | WEAR RING ROD, 88.9″ID, 3.18″ SECTION, 1 | HP800 | 0.020 |
| 1063193001 | PISTON WEAR RING 1.5″W X 21.907″ BORE, | HP800 | 0.330 |
| 1063518520 | SEAL RING SEGMENT | HP800 | 0.907 |
| 1063518530 | SEAL RING SEGMENT | HP800 | 1.360 |
| 1063518785 | RING SEGMENT SEAL | HP800 | 1.360 |
| 1063519865 | DUST SEAL DUST SHELL SEAL | HP800 | 3.629 |
| 1063915673 | TORCH RING | HP800 | 24.490 |
| 1063917765 | CNTRWGHT LINER | HP800 | 324.000 |
| 1068636577 | CNTRSHFT | HP800 | 241.000 |
| 1068868598 | MAIN SHAFT FINISHED | HP800 | 2,225.000 |
| 1072926702 | WEAR RING HEAD – MACHING | HP800 | 19.900 |
| 1073044087 | SPACER | HP800 | 0.620 |
| 1073817098 | SOCKET | HP800 | 222.000 |
| 1079141222 | PRSSR ACCUMULATOR POWER UNIT, 1.0 GAL-ST | HP800 | 16.290 |
| 1079141224 | PRESSURE ACCUMULATOR 1.0 GALLON, 3000 PS | HP800 | 36.000 |
| 1079142722 | PRSSR ACCUMULATOR 2.5 GAL, #24 SAE PORT | HP800 | 36.360 |
| 1079844029 | ADAPTER E30024 | HP800 | 0.100 |
| 1083390657 | VALVE ASSY VALVE MODULE | HP800 | 62.000 |
| 1086343192 | WEDGE | HP800 | 8.600 |
| 1086428470 | CNTRWGHT | HP800 | 1,929.000 |
| 1093070001 | CLAMPING CYL | HP800 | 11.670 |
| 1093070002 | CLAMP CYL REP KIT | HP800 | 0.040 |
| 1093070045 | TRAMP RELEASE CYL | HP800 | 214.000 |
| 1093070046 | REPAIRING KIT HP800 TRAMP RELEASE CYLIN | HP800 | 0.690 |
| 1093080001 | SOCKET ASSY | HP800 | 413.000 |
| 1093080005 | TRAMP RELEASE ASSY | HP800 | 3,016.000 |
| 1093080009 | BOWL ASSEMBLY SHORT HEAD | HP800 | 9,658.000 |
| 1093080073 | HEAD ASSY | HP800 | 6,025.000 |
| 1093080079 | CNTRSHFT ASSY OUTER BSHG GRV AT 6:00 O’C | HP800 | 1,403.000 |
| 1093080117 | BOWL ASSY STANDARD | HP800 | 10,706.000 |
| 1093080118 | BOWL ASSY SHORT HEAD | HP800 | 10,521.000 |
| 1093080129 | ADJSTM RING ASSY | HP800 | 8,551.000 |
| 1093080144 | ECCENTRIC ASSY STRAIGHT BEVEL GEAR | HP800 | 5,248.000 |
| 1093080167 | VIBR SNSR ASSY SKF SYSTEM, S/B MM0222 | HP800 | 93.000 |
| 1093080180 | CNTRSHFT BOX ASSY DIRECT DRIVE, 6:00 GRO | HP800 | 1,400.000 |
| 1093080219 | CNTRSHFT BOX ASSY 6:00 O’CLOCK GROOVE, S | HP800 | 1,400.000 |
| 1093085007 | TIE-ROD KIT MANIFOLD | HP800 | 0.180 |
| 1093085008 | SEAL KIT MANIFOLD O-RING KIT | HP800 | 0.010 |
| 1093085016 | PRSSR ACCUMULATOR ASSY, 2.5 GAL – STD, # | HP800 | 36.000 |
| 1093085022 | CNTRWGHT SUB-ASSEMBLY | HP800 | 2,253.000 |
| 1093085026 | HYDRAULIC DRIVE UNIT SUBASSEMBLY | HP800 | 128.000 |
| 1093085027 | HYDRAULIC DRIVE UNIT GEARBOX RATIO 117- | HP800 | 149.000 |
| 1093085029 | ADJSTM RING SUB-ASSEMBLY | HP800 | 6,853.000 |
| 1093085033 | ECCENTRIC SUB-ASSEMBLY | HP800 | 3,062.000 |
| 1093085034 | HYDR DRIVE | HP800 | 146.000 |
| 1093085042 | MAIN FRAME ASSY SUB ASSEMBLY | HP800 | 18,160.000 |
| 1094399989 | BLADDER ASSEMBLY P/N R2.5-101-10 | HP800 | 1.470 |
| 1094400127 | REPAIRING KIT 2.50″-15, R11-102 | HP800 | 0.400 |
| 1094400147 | REPAIRING KIT BLADDER REPAIR KIT, P/N 08 | HP800 | 0.520 |
| 1094506043 | CONTROL BOX P.B. CONTROL BOX | HP800 | 0.000 |
| 1094506606 | HYDRAULIC POWER UNIT MOTOR ADJUSTMENT | HP800 | 0.000 |
| 10P0113701 | JACKSHAFT 4140 ANNEALED | HP800 | 418.000 |
| 10P0113702 | KEY SHEAVE | HP800 | 2.858 |
| 10P0428101 | GRID MODULE COVER GRID ASSEMBLY + | HP800 | 0.000 |
| 10P0428102 | GRID SHAFT COUPLING T-GRID, P/N 0758257 | HP800 | 5.440 |
| 10P0430608 | COVER COUPLING COVER TYPE T20 SIZE 1140T | HP800 | 0.000 |
| 10P0820703 | BRNG INBOARD JACKSHAFT INBOARD P.B. BEA | HP800 | 0.000 |
| 17-107-513-207 | THERMOWELL 1.25 NPTM X M30 INTERNAL TEF | HP800 | 0.110 |
| MM0200329 | MAIN FRAME ASSY W / ECCENTRIC BUSHING R | HP800 | 19,595.000 |
| MM0218101 | PRSSR TRANSMITTER IFM EFECTOR P/N 2221, | HP800 | 0.300 |
| MM0222107 | VIBR SNSR ASSY SKF SYSTEM, ANALOG ONLY | HP800 | 87.000 |
| MM0226766 | PRSSR TRANSMITTER 8W2D44K12, ONE SERIES | HP800 | 0.970 |
| MM0232175 | PRESSURE SWITCH ASSEMBLY PS-3 RETROFIT K | HP800 | 1.050 |
| MM0235083 | ELCTRC MOTOR 20HP/1180RPM/286T FR/460V/ | HP800 | 130.000 |
| MM0239120 | BRACKET TURNING, FOR SHORT BOWL | HP800 | 16.800 |
| MM0239581 | LEVEL DETECTOR CONTROLLER 7ML5004-1AA10 | HP800 | 3.180 |
| MM0241495 | REMOTE HANDSET 7ML1830-2AN | HP800 | 0.000 |
| MM0275088 | HYDR POWER UNIT ORDER DWG/380V/3PH/50HZ | HP800 | 907.000 |
| MM0309211 | POWER SUPPLY RETROFIT KIT, 24VDC, 300W, | HP800 | 1.500 |
| MM0323822 | PILLOW BLOCK SAF 532 | HP800 | 66.500 |
| MM0347063 | PRSSR REL VALVE RVPP-10-N-S-0-50/2950PSI | HP800 | 0.680 |
| N02125059 | THERMOSTAT ATEMNC | HP800 | 0.408 |
| N02125711 | AIR BREATHER MODEL NO. SF6710, 2000 PSI | HP800 | 1.220 |
| N02150054 | PUMP P7500C367AXSPLNY3000ASPLNY301DVS | HP800 | 77.560 |
| N02154802 | HEAT EXCHANGER ITT P/ N HCF-B-06048 | HP800 | 49.440 |
| N02445170 | DIRECTIONAL VALVE DSG-03-3C-4-A200-0-N- | HP800 | 3.740 |
| N02445872 | SOLENOID VALVE EMDV-10-N-3A-0-230A-G | HP800 | 0.830 |
| N02445873 | SOLENOID VALVE EMDV-10-N-C2-0-230A-G | HP800 | 0.840 |
| N02445874 | SOLENOID VALVE EMDV-12-N-4AQ-230A-G | HP800 | 1.000 |
| N02445875 | SOLENOID VALVE EMDV-12-N-01-0-230A-G | HP800 | 1.000 |
| N02445876 | SOLENOID VALVE SV3-10-0-0-240A-G | HP800 | 1.000 |
| N02445877 | SOLENOID VALVE EMDV-12N-C2-1STA-230A-G | HP800 | 1.000 |
| N02445957 | DIRECTIONAL VALVE D3W4C-NJWF | HP800 | 6.360 |
| N02445960 | SOLENOID VALVE SV3-10-0-0-24-DG | HP800 | 0.520 |
| N02445963 | SOLENOID VALVE EMDV-12-N-4A0-24-DG | HP800 | 1.030 |
| N02445969 | SOLENOID VALVE DSL101C-D024LD | HP800 | 0.540 |
| N02445970 | SOLENOID VALVE DS162C-D024 | HP800 | 1.240 |
| N02445971 | SOLENOID VALVE SBV11-12-0-024DG | HP800 | 0.180 |
| N02456156 | PILOT OPERATED CHECK VALVE POC1-10-F-0-0 | HP800 | 0.200 |
| N02480792 | PUMP PVP41 36 L2 P | HP800 | 26.000 |
| N02482201 | FLOW CONTROL VALVE 67173 | HP800 | 13.630 |
| N02482859 | PROTECTION TUBE 67808 | HP800 | 0.450 |
| N02495159 | PROGR LOGICCTRLLER MICROLOGIX 1500 BASE | HP800 | 1.100 |
| N02495160 | MEMORY 1764-MM1 | HP800 | 0.010 |
| N02495454 | BREAKER 1492-GH010 | HP800 | 0.000 |
| N02495455 | RELAY 700-HK36Z24 | HP800 | 0.000 |
| N02495939 | FUSE HOLDER 1492-H6 | HP800 | 0.000 |
| N05228038 | PROXIMITY SW BI10-G30-YOX | HP800 | 0.190 |
| N05256355 | PUSH BUTTON 800TC-FXJ6D4 | HP800 | 0.000 |
| N05256423 | ELCTRC CABLE NETWORK CABLE, 1761-CBL-PM | HP800 | 0.030 |
| N07503100 | GREASE 80878, MOLY GRADE ANTI-SEIZE M42 | HP800 | 21.940 |
Related Articles
